Gel-filled cable joint with two-component insulation for extruded cables
- Joint with self-sealing polymer insulation
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Can be used in place of cast resin joints
Insulation characteristicsNon-toxic
- Insulating
- Permanently flexible
- Low exothermic peaks
- Cross-linkage in less than 10 minutes at room temperature
Description
Gel-filled cable joint with two-component insulation for extruded cables
- Joint with self-sealing polymer insulation
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Can be used in place of cast resin joints
Insulation characteristicsNon-toxic
- Insulating
- Permanently flexible
- Low exothermic peaks
- Cross-linkage in less than 10 minutes at room temperature
Magic Joint Y
Cable joint with 30o branch and two-component insulation for extruded cables
- Joint with self-sealing polymer insulation
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Can be used in place of cast resin joints
Insulation characteristics
- Non-toxic
- Insulating
- Permanently flexible
- Low exothermic peaks
- Cross-linkage in less than 10 minutes at room temperature
Magic Gel
Two-component gel with good dielectric and thermal characteristics
- For voltages to 1kV
- Guarantees protection of higher than IP68
- For installations to 120 o C
Insulation characteristics
- Non-toxic
- Insulating
- Polymerization even at low temperatures
- Cross-linkage in less than 10 minutes at room temperature
- Unlimited shelf life
- Reusable
Clik 2000/2001/2002/2003-Fire
Fire-resistant with 30 o branch and gel-filled/rapid joint for extruded cables
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Conforms to Class 2 of Standard CEI 61 -8
- For mechanically-loaded installations
- For use at very high humidity
- Suitable for cables with operating temperatures to 90 o C
Clik 0/1/2-Fire
Gel-filled flame-resistant rapid joint or joint with multiple branches for extruded cables.
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Conforms to Class 2 of Standard CEI 61 -8
- For mechanically-loaded installations
- For use at very high humidity
- Suitable for cables with operating temperatures to 90 o C
Rapid Joint
Straight, rapid gel-filled joint with radial closing for extruded cables
- For voltages from 0.6 to 1kV
- Guarantees protection of higher than IP68
- Conforms to Class 2 of Standard CEI 64 8
- For mechanically-loaded installations
- For use at very high humidity
Characteristics
- Flame-resistant to CEI 20-35, IEC 332-1 CENELEC HD 405-1
- Self-extinguishing
- Polymerization even at low temperatures
- Cross-linkage in less than 10 minutes at room temperature
*The CJS-RJL95C2595 Rapid Joint has 4 screw connectors with pre-determined
fracture for cross-sections from 25 to 95 mm 2 .
